OEM YUKEN 50T 150T Series 150T-75-L-RL-40 Hydraulic Rotary Vane Oil Pumps | Partsdic®

The 150T-75-L-RL-40 model belongs to the 150T series and is specifically designed to handle medium to high-pressure hydraulic systems.

It offers a maximum pressure capacity of 150 bar (or 2175 psi) and has a displacement of 75 cc/rev, making it suitable for a wide range of industrial applications.

One of the key features of this hydraulic pump is its rotary vane design. The pump consists of a rotor with multiple vanes that rotate within a cam ring. As the rotor rotates, the vanes slide in and out of the rotor slots, creating chambers that trap and transport hydraulic fluid. This design ensures smooth and consistent fluid flow, reducing noise and vibration levels.

The 150T-75-L-RL-40 pump is equipped with a suction port and a pressure port, allowing easy integration into hydraulic systems. It is designed for clockwise rotation when viewed from the shaft end (L), and it features a rear port location (RL). This configuration provides flexibility in system design and allows for easy installation in various orientations.

With its compact and lightweight construction, the pump is highly versatile and can be used in a variety of applications, including machine tools, injection molding machines, hydraulic presses, and industrial machinery. It can handle a wide range of hydraulic fluids, including mineral oils, water-glycol fluids, and phosphate ester-based fluids, making it suitable for different operating environments.

The 150T-75-L-RL-40 pump incorporates high-quality materials and precise manufacturing techniques to ensure long-lasting performance and reliability.

It features a cast iron housing that provides excellent strength and resistance to wear. The vanes are made of hardened steel to withstand demanding operating conditions and prolong the pump's service life.

To enhance operational efficiency, the pump is designed with low internal leakage, minimizing energy losses and optimizing system performance. Additionally, it incorporates advanced sealing technologies to prevent fluid leakage and maintain system integrity.

Maintenance and servicing of the 150T-75-L-RL-40 pump are straightforward. It is recommended to regularly check the fluid levels and condition, and to perform routine inspections to identify any signs of wear or damage. The pump is designed for easy disassembly and reassembly, facilitating quick maintenance procedures and minimizing downtime.
